External Secrets Operator: Kubernetes Secret Sync from AWS, Vault, GCP (2026)

Kubernetes Secrets solve the "how do I get configuration into a pod" problem, but they don't solve the "how do I manage secrets securely" problem. A Secret stored in etcd is base64-encoded (not encrypted by default), visible to anyone with kubectl get secret, and synced to every node where a pod might run. Actual secret management — rotation, access control, audit logging, encryption at rest — lives in dedicated secret stores: AWS Secrets Manager, HashiCorp Vault, GCP Secret Manager, Azure Key Vault.

External Secrets Operator (ESO, CNCF Sandbox) bridges these stores and Kubernetes: you declare in a Kubernetes resource which external secret you need, and ESO syncs it into a Kubernetes Secret on a configurable interval. When the secret rotates in the external store, ESO picks up the new value and updates the Kubernetes Secret automatically.

Architecture

ESO introduces four main concepts:

Resource	Scope	Purpose
`SecretStore`	Namespace	Access credentials to one secret store backend (per namespace)
`ClusterSecretStore`	Cluster	Same as SecretStore, but usable from any namespace
`ExternalSecret`	Namespace	Declares which secret to sync and where to store it
`PushSecret`	Namespace	Writes a Kubernetes Secret to an external store (reverse direction)

The typical production pattern: one ClusterSecretStore per secret store backend (AWS Secrets Manager, Vault), multiple ExternalSecret resources across application namespaces referencing that store.

Installation

bash

1helm repo add external-secrets https://charts.external-secrets.io
2helm repo update
3
4helm install external-secrets external-secrets/external-secrets \
5  --namespace external-secrets \
6  --create-namespace \
7  --set crds.install=true

Verify the controller is running and the webhook is healthy:

bash

kubectl get pods -n external-secrets
# NAME                                        READY   STATUS    AGE
# external-secrets-xxxxx                      1/1     Running   2m
# external-secrets-webhook-xxxxx              1/1     Running   2m
# external-secrets-cert-controller-xxxxx      1/1     Running   2m

AWS Secrets Manager

ClusterSecretStore with IRSA or Pod Identity

ESO's controller needs IAM permissions to read from Secrets Manager. Using EKS Pod Identity (no OIDC required):

bash

# Create the IAM role and PodIdentityAssociation
aws eks create-pod-identity-association \
  --cluster-name my-cluster \
  --namespace external-secrets \
  --service-account external-secrets \
  --role-arn arn:aws:iam::123456789:role/external-secrets-role

IAM policy for the role:

json

1{
2  "Version": "2012-10-17",
3  "Statement": [
4    {
5      "Effect": "Allow",
6      "Action": [
7        "secretsmanager:GetSecretValue",
8        "secretsmanager:DescribeSecret"
9      ],
10      "Resource": "arn:aws:secretsmanager:us-east-1:123456789:secret:production/*"
11    }
12  ]
13}

With EKS Pod Identity (recommended — no OIDC configuration needed), the auth block can be omitted entirely. The AWS SDK default credential chain resolves credentials from the Pod Identity endpoint automatically:

yaml

1# ClusterSecretStore with Pod Identity — no explicit auth block needed
2apiVersion: external-secrets.io/v1beta1
3kind: ClusterSecretStore
4metadata:
5  name: aws-secretsmanager
6spec:
7  provider:
8    aws:
9      service: SecretsManager
10      region: us-east-1
11      # No auth block: AWS SDK picks up Pod Identity credentials from
12      # http://169.254.170.23/v1/credentials automatically

With IRSA (OIDC-based, older approach), specify the controller's service account explicitly:

yaml

1# ClusterSecretStore with IRSA
2apiVersion: external-secrets.io/v1beta1
3kind: ClusterSecretStore
4metadata:
5  name: aws-secretsmanager
6spec:
7  provider:
8    aws:
9      service: SecretsManager
10      region: us-east-1
11      auth:
12        jwt:
13          serviceAccountRef:
14            name: external-secrets         # ESO controller's ServiceAccount
15            namespace: external-secrets

The jwt auth block explicitly presents the controller's projected service account token to the IRSA STS endpoint for federation.

ExternalSecret

yaml

1apiVersion: external-secrets.io/v1beta1
2kind: ExternalSecret
3metadata:
4  name: database-credentials
5  namespace: production
6spec:
7  refreshInterval: 1h           # Re-sync from Secrets Manager every hour
8  secretStoreRef:
9    name: aws-secretsmanager
10    kind: ClusterSecretStore
11  target:
12    name: database-credentials  # Kubernetes Secret name to create/update
13    creationPolicy: Owner       # ESO owns this Secret (deletes it when ExternalSecret is deleted)
14    deletionPolicy: Retain      # Keep the K8s Secret if ExternalSecret is deleted (safer for prod)
15  data:
16    # Map individual JSON fields from the external secret to K8s Secret keys
17    - secretKey: DB_PASSWORD
18      remoteRef:
19        key: production/myapp/database    # AWS Secrets Manager secret name
20        property: password                # JSON field within the secret
21    - secretKey: DB_USERNAME
22      remoteRef:
23        key: production/myapp/database
24        property: username

If the AWS secret is a JSON object and you want all its keys as separate Secret data entries:

yaml

  dataFrom:
    - extract:
        key: production/myapp/database
        # Creates K8s Secret keys: password, username, host, port
        # from the JSON object {"password":"...","username":"...","host":"...","port":"..."}

Check ExternalSecret status:

bash

1kubectl get externalsecret -n production
2# NAME                   STORE               REFRESH INTERVAL   STATUS         READY
3# database-credentials   aws-secretsmanager  1h                 SecretSynced   True
4
5kubectl describe externalsecret database-credentials -n production
6# Status:
7#   Conditions:
8#     Type:    Ready
9#     Status:  True
10#     Reason:  SecretSynced
11#     Message: Secret was synced
12#   Refresh Time: 2026-05-09T10:00:00Z

AWS SSM Parameter Store

SSM Parameter Store is preferred over Secrets Manager for non-sensitive configuration and for secrets that don't need the rotation/versioning features of Secrets Manager:

yaml

1apiVersion: external-secrets.io/v1beta1
2kind: ClusterSecretStore
3metadata:
4  name: aws-ssm
5spec:
6  provider:
7    aws:
8      service: ParameterStore
9      region: us-east-1
10      auth:
11        jwt:
12          serviceAccountRef:
13            name: external-secrets
14            namespace: external-secrets
15---
16apiVersion: external-secrets.io/v1beta1
17kind: ExternalSecret
18metadata:
19  name: app-config
20  namespace: production
21spec:
22  refreshInterval: 15m
23  secretStoreRef:
24    name: aws-ssm
25    kind: ClusterSecretStore
26  target:
27    name: app-config
28  dataFrom:
29    - find:
30        path: /production/myapp    # Sync all parameters under this path
31        name:
32          regexp: ".*"

The find directive syncs all SSM parameters under /production/myapp/ as separate Secret keys. A parameter /production/myapp/DATABASE_URL becomes DATABASE_URL in the Kubernetes Secret.

HashiCorp Vault

ESO connects to Vault using the Kubernetes auth method — Vault validates the pod's projected service account token against the cluster's OIDC endpoint:

bash

1# Configure Vault Kubernetes auth (one-time setup)
2vault auth enable kubernetes
3
4vault write auth/kubernetes/config \
5  kubernetes_host="https://kubernetes.default.svc.cluster.local" \
6  kubernetes_ca_cert=@/var/run/secrets/kubernetes.io/serviceaccount/ca.crt
7
8# Create a Vault policy for ESO
9vault policy write external-secrets-policy - <<EOF
10path "secret/data/production/*" {
11  capabilities = ["read"]
12}
13EOF
14
15# Bind the policy to the ESO service account
16vault write auth/kubernetes/role/external-secrets \
17  bound_service_account_names=external-secrets \
18  bound_service_account_namespaces=external-secrets \
19  policies=external-secrets-policy \
20  ttl=1h

yaml

1apiVersion: external-secrets.io/v1beta1
2kind: ClusterSecretStore
3metadata:
4  name: vault-backend
5spec:
6  provider:
7    vault:
8      server: "https://vault.example.com"
9      path: "secret"    # KV v2 mount path
10      version: "v2"     # KV v2 API
11      auth:
12        kubernetes:
13          mountPath: "kubernetes"       # Vault auth mount
14          role: "external-secrets"      # Vault role
15          serviceAccountRef:
16            name: external-secrets
17            namespace: external-secrets
18---
19apiVersion: external-secrets.io/v1beta1
20kind: ExternalSecret
21metadata:
22  name: vault-secret
23  namespace: production
24spec:
25  refreshInterval: 30m
26  secretStoreRef:
27    name: vault-backend
28    kind: ClusterSecretStore
29  target:
30    name: vault-secret
31  dataFrom:
32    - extract:
33        key: production/myapp/config    # Vault KV path (without "data/" prefix for v2)

Secret Templating

ESO can transform external secret data using Go templates before writing to the Kubernetes Secret. This is useful for constructing connection strings, Docker config JSON, or other formatted values:

yaml

1spec:
2  target:
3    name: app-credentials
4    template:
5      engineVersion: v2
6      type: Opaque
7      data:
8        # Construct a database URL from individual fields
9        DATABASE_URL: "postgresql://{{ .username }}:{{ .password }}@{{ .host }}:{{ .port }}/{{ .dbname }}?sslmode=require"
10        # Base64-encode a value
11        ENCODED_KEY: "{{ .api_key | b64enc }}"
12  dataFrom:
13    - extract:
14        key: production/myapp/database

For Docker registry credentials (imagePullSecret):

yaml

1  target:
2    template:
3      type: kubernetes.io/dockerconfigjson
4      data:
5        .dockerconfigjson: |
6          {
7            "auths": {
8              "{{ .registry }}": {
9                "username": "{{ .username }}",
10                "password": "{{ .password }}",
11                "auth": "{{ printf "%s:%s" .username .password | b64enc }}"
12              }
13            }
14          }

Generators

Generators create secrets dynamically rather than syncing them from an external store:

yaml

1# ECR authorization token — automatically refreshed every 12h
2apiVersion: generators.external-secrets.io/v1alpha1
3kind: ECRAuthorizationToken
4metadata:
5  name: ecr-token
6  namespace: production
7spec:
8  region: us-east-1
9  auth:
10    jwt:
11      serviceAccountRef:
12        name: external-secrets
13        namespace: external-secrets
14---
15# Reference the generator from an ExternalSecret
16apiVersion: external-secrets.io/v1beta1
17kind: ExternalSecret
18metadata:
19  name: ecr-pull-secret
20  namespace: production
21spec:
22  refreshInterval: 6h
23  dataFrom:
24    - sourceRef:
25        generatorRef:
26          apiVersion: generators.external-secrets.io/v1alpha1
27          kind: ECRAuthorizationToken
28          name: ecr-token
29  target:
30    name: ecr-pull-secret
31    template:
32      type: kubernetes.io/dockerconfigjson

Other generators include Password (generate random passwords), GCRAccessToken, and VaultDynamicSecret (generate dynamic Vault credentials for each reconciliation).

Monitoring

yaml

1# Key metrics:
2# externalsecrets_sync_calls_total{name, namespace, status}
3# externalsecrets_sync_call_errors_total{name, namespace}
4# externalsecrets_store_last_sync_error_condition
5
6# Alert: ExternalSecret failing to sync
7- alert: ExternalSecretSyncFailed
8  expr: externalsecrets_sync_call_errors_total > 0
9  for: 15m
10  labels:
11    severity: critical
12  annotations:
13    summary: "ExternalSecret {{ $labels.name }} in {{ $labels.namespace }} failing to sync"
14
15# Alert: ExternalSecret sync error rate
16- alert: ExternalSecretSyncError
17  expr: rate(externalsecrets_sync_calls_total{status="error"}[5m]) > 0
18  for: 5m
19  annotations:
20    summary: "ExternalSecret sync failing"

Frequently Asked Questions

Should I use ESO or SOPS for secrets in GitOps?

ESO and SOPS solve different problems. SOPS encrypts secret values and commits the encrypted form to Git — the secret material lives in your repository (encrypted). ESO keeps secret material out of Git entirely — it lives only in the external store. For new platforms, ESO is the better pattern: secrets are managed in AWS Secrets Manager / Vault (with proper IAM, rotation, and audit logging), and ESO syncs them into Kubernetes. SOPS is simpler to operate (no secret store required) but gives you less operational control over secret lifecycle. For Flux-managed clusters, ESO is typically preferred over SOPS in organisations that already have a secret store. See Flux CD GitOps for how Flux recommends ESO alongside GitOps.

What happens to the Kubernetes Secret if the external secret is deleted?

Controlled by target.deletionPolicy:

Delete (default): Kubernetes Secret is deleted when the ExternalSecret is deleted
Retain: Kubernetes Secret persists after ExternalSecret deletion — safer for production secrets that applications may still reference
Merge: External data keys are removed from the Secret, but keys added by other sources remain

For production secrets that applications depend on, use deletionPolicy: Retain to prevent accidental deletion of in-use Secrets when cleaning up ExternalSecrets.

Can ESO trigger a pod restart when a secret rotates?

Not directly — ESO updates the Kubernetes Secret value, but running pods won't see the change until they restart. Options:

Mount secrets as environment variables with a sidecar that polls for changes (Reloader/Stakater)
Use volume-mounted Secrets — pods can watch for inotify changes on the mounted file (but most apps don't do this)
Deploy Reloader (stakater/Reloader), which watches for Secret/ConfigMap changes and automatically restarts Deployments that reference them

Is there a way to test ExternalSecret configuration without creating a real Kubernetes Secret?

bash

1# Use ESO's SecretStore validation
2kubectl get clustersecretstores
3# Check READY column — True means the store is reachable and credentials work
4
5# Force an immediate sync
6kubectl annotate externalsecret database-credentials \
7  force-sync.external-secrets.io/reconcile-at=$(date +%s) \
8  -n production

After rotating secrets, running pods won't pick up the new values until they restart — see Kubernetes PodDisruptionBudget and Graceful Shutdown Patterns for how to restart pods with zero downtime using PDBs. For GitOps workflows that manage ESO's own configuration declaratively, see Flux CD: GitOps for Kubernetes. For how ESO replaces SOPS in GitOps secret management, and for the broader platform architecture, see Platform Engineering: Building an Internal Developer Platform. For EKS Pod Identity setup (used for ESO's AWS auth), see EKS Networking Deep Dive. For advanced ESO patterns — multiple SecretStore backends, PushSecret for writing secrets back to external stores, and ESO monitoring — see External Secrets Operator: Syncing AWS, GCP, and Vault Secrets to Kubernetes.

Setting up centralised secret management across a multi-cluster Kubernetes platform? Talk to us at Coding Protocols — we help platform teams connect their secret stores to Kubernetes without storing credentials in Git.

External Secrets Operator: Syncing Secrets from AWS, Vault, and GCP

Architecture

Installation

AWS Secrets Manager

ClusterSecretStore with IRSA or Pod Identity

ExternalSecret

AWS SSM Parameter Store

HashiCorp Vault

Secret Templating

Generators

Monitoring

Frequently Asked Questions

Should I use ESO or SOPS for secrets in GitOps?

What happens to the Kubernetes Secret if the external secret is deleted?

Can ESO trigger a pod restart when a secret rotates?

Is there a way to test ExternalSecret configuration without creating a real Kubernetes Secret?

Related Topics

Read Next

External Secrets Operator: Syncing AWS, GCP, and Vault Secrets to Kubernetes

Falco Runtime Security: Protecting Kubernetes Clusters from the Inside

Kubernetes NetworkPolicy: Zero-Trust Networking for Multi-Team Clusters
