External Secrets Operator: Syncing AWS, GCP, and Vault Secrets to Kubernetes
External Secrets Operator (ESO) syncs secrets from external stores (AWS Secrets Manager, GCP Secret Manager, HashiCorp Vault, Azure Key Vault) into Kubernetes Secrets. It eliminates the practice of committing secret values to Git while keeping them available to pods as standard Kubernetes Secrets. This covers ESO installation, SecretStore and ClusterSecretStore configuration for AWS and Vault, ExternalSecret resource definitions, refreshInterval-based rotation, generators for dynamic secrets, and the PushSecret pattern for writing from Kubernetes back to external stores.
Kubernetes Secrets are not secret. They're base64-encoded data stored in etcd, accessible to anyone with the right RBAC permissions, and frequently end up committed to Git in Helm values or Kubernetes manifests. External Secrets Operator (ESO) solves the source-of-truth problem: secrets live in a dedicated secrets store (AWS Secrets Manager, HashiCorp Vault, GCP Secret Manager), and ESO syncs them to Kubernetes Secrets on a configurable interval. Applications consume the Kubernetes Secret as before — no code changes required.
The sync model means you never store secret values in Git. You store only the reference: which path in Secrets Manager maps to which Kubernetes Secret. The actual values stay in the external store.
Installation
1helm repo add external-secrets https://charts.external-secrets.io
2helm repo update
3
4# Check https://github.com/external-secrets/external-secrets/releases for latest
5helm install external-secrets \
6 external-secrets/external-secrets \
7 --namespace external-secrets \
8 --create-namespace \
9 --version 0.10.7 \
10 --set crds.install=true # installCRDs=true was deprecated in v0.9; crds.install=true is correct for v0.9+Verify:
kubectl get pods -n external-secrets
# external-secrets-<hash> Running
# external-secrets-cert-controller-<hash> Running
# external-secrets-webhook-<hash> RunningAWS Secrets Manager: SecretStore Setup
SecretStore is namespace-scoped: it can only be used by ExternalSecret resources in the same namespace. Configure one per team namespace using IRSA or Pod Identity for per-namespace IAM isolation.
1apiVersion: external-secrets.io/v1beta1
2kind: SecretStore
3metadata:
4 name: aws-secretsmanager
5 namespace: payments
6spec:
7 provider:
8 aws:
9 service: SecretsManager
10 region: us-east-1
11 auth:
12 jwt:
13 serviceAccountRef:
14 name: payments-eso-sa # ServiceAccount with Pod Identity or IRSA annotationCreate the ServiceAccount with Pod Identity:
aws eks create-pod-identity-association \
--cluster-name production \
--namespace payments \
--service-account payments-eso-sa \
--role-arn arn:aws:iam::${AWS_ACCOUNT_ID}:role/ESOPaymentsReaderThe IAM role needs secretsmanager:GetSecretValue and secretsmanager:DescribeSecret on the target secrets:
1{
2 "Effect": "Allow",
3 "Action": [
4 "secretsmanager:GetSecretValue",
5 "secretsmanager:DescribeSecret"
6 ],
7 "Resource": "arn:aws:secretsmanager:us-east-1:*:secret:payments/*"
8}ClusterSecretStore: Cluster-Wide Provider
ClusterSecretStore is cluster-scoped — any ExternalSecret in any namespace can reference it. Use it for centralized secrets (shared infrastructure credentials, TLS CA) while using namespace-scoped SecretStore for team-specific secrets.
1apiVersion: external-secrets.io/v1beta1
2kind: ClusterSecretStore
3metadata:
4 name: aws-global
5spec:
6 provider:
7 aws:
8 service: SecretsManager
9 region: us-east-1
10 auth:
11 jwt:
12 serviceAccountRef:
13 name: eso-cluster-sa
14 namespace: external-secrets # ClusterSecretStore SA must specify namespaceExternalSecret: Syncing a Secret
1apiVersion: external-secrets.io/v1beta1
2kind: ExternalSecret
3metadata:
4 name: payments-db-credentials
5 namespace: payments
6spec:
7 refreshInterval: 1h # Re-sync from AWS every hour; rotation window
8
9 secretStoreRef:
10 name: aws-secretsmanager
11 kind: SecretStore # or ClusterSecretStore
12
13 target:
14 name: payments-db-secret # The Kubernetes Secret to create/update
15 creationPolicy: Owner # ESO owns this Secret; deletes it when ExternalSecret is deleted
16 template:
17 type: Opaque
18 data:
19 # Transform: construct connection string from individual secret fields
20 DATABASE_URL: "postgresql://{{ .username }}:{{ .password }}@{{ .host }}:{{ .port }}/payments"
21
22 data:
23 # Map AWS Secrets Manager fields to Kubernetes Secret keys
24 - secretKey: username # Key in the Kubernetes Secret
25 remoteRef:
26 key: payments/database # Path in AWS Secrets Manager
27 property: username # JSON field within the secret (if the secret is JSON)
28
29 - secretKey: password
30 remoteRef:
31 key: payments/database
32 property: password
33
34 - secretKey: host
35 remoteRef:
36 key: payments/database
37 property: hostCheck sync status:
kubectl get externalsecret payments-db-credentials -n payments
# NAME STORE REFRESH INTERVAL STATUS READY
# payments-db-credentials aws-secretsmanager 1h Valid True
kubectl describe externalsecret payments-db-credentials -n payments
# Events: Synchronized successfullyBulk Sync with dataFrom
If your AWS secret is a JSON object and you want all fields as Kubernetes Secret keys without listing them individually:
spec:
dataFrom:
- extract:
key: payments/database # All JSON fields from this secret become Secret keysThis creates a Kubernetes Secret with keys username, password, host, port — one key per top-level JSON field in the AWS secret.
HashiCorp Vault SecretStore
1apiVersion: external-secrets.io/v1beta1
2kind: ClusterSecretStore
3metadata:
4 name: vault-backend
5spec:
6 provider:
7 vault:
8 server: https://vault.vault.svc.cluster.local:8200
9 path: secret # KV v2 secrets mount path
10 version: v2 # KV v2 API
11 caBundle: <base64-vault-ca> # Vault's TLS CA
12
13 auth:
14 kubernetes:
15 mountPath: kubernetes
16 role: eso-reader # Vault Kubernetes auth role
17 serviceAccountRef:
18 name: eso-cluster-sa
19 namespace: external-secrets1# ExternalSecret referencing Vault KV v2
2apiVersion: external-secrets.io/v1beta1
3kind: ExternalSecret
4metadata:
5 name: payments-stripe-keys
6 namespace: payments
7spec:
8 refreshInterval: 30m
9 secretStoreRef:
10 name: vault-backend
11 kind: ClusterSecretStore
12 target:
13 name: stripe-credentials
14 creationPolicy: Owner
15 data:
16 - secretKey: STRIPE_SECRET_KEY
17 remoteRef:
18 key: payments/stripe # Path relative to the KV v2 mount (ESO prepends /data/ automatically; don't include it)
19 property: secret_keySecret Rotation: refreshInterval and Reloading
ESO re-fetches the secret from the external store on every refreshInterval. If the value changed (e.g., you rotated the database password in Secrets Manager), the Kubernetes Secret is updated automatically within the interval.
Pods don't automatically restart when the Secret changes. The Kubernetes Secret is a volume mount or environment variable — pods only see the change when they restart. Two options:
- Stakater Reloader: a separate controller that watches Secrets and ConfigMaps and restarts Deployments when they change.
helm install reloader stakater/reloader --namespace reloader-system# Annotation on the Deployment triggers Reloader to watch the secret
metadata:
annotations:
reloader.stakater.com/auto: "true"- Volume mount with periodic reload: mount the Secret as a volume (not envFrom). Kubernetes updates the volume when the Secret changes without restarting the pod — only if your application watches the file and reloads it.
Generators: Dynamic Secrets
ESO generators create secrets dynamically at sync time. The ECRAuthorizationToken generator fetches an ECR login token (valid for 12 hours):
1apiVersion: generators.external-secrets.io/v1alpha1
2kind: ECRAuthorizationToken
3metadata:
4 name: ecr-token
5 namespace: payments
6spec:
7 region: us-east-1The generator produces keys username, password, and proxy_endpoint. Use a template to construct the dockerconfigjson from those values:
1apiVersion: external-secrets.io/v1beta1
2kind: ExternalSecret
3metadata:
4 name: ecr-pull-secret
5 namespace: payments
6spec:
7 refreshInterval: 6h # Refresh before the 12h token expires
8 dataFrom:
9 - sourceRef:
10 generatorRef:
11 apiVersion: generators.external-secrets.io/v1alpha1
12 kind: ECRAuthorizationToken
13 name: ecr-token
14 target:
15 name: ecr-pull-credentials
16 template:
17 type: kubernetes.io/dockerconfigjson
18 data:
19 # Construct dockerconfigjson from the generator's username/password/proxy_endpoint fields
20 .dockerconfigjson: |
21 {"auths":{"{{ .proxy_endpoint }}":{"username":"{{ .username }}","password":"{{ .password }}","auth":"{{ printf "%s:%s" .username .password | b64enc }}"}}}This keeps ECR pull credentials fresh without storing a static Docker config in the cluster.
PushSecret: Writing to External Stores
PushSecret is the inverse — it writes a Kubernetes Secret (typically auto-generated) to an external store. Useful for distributing a Kubernetes-generated certificate or database password to other systems:
1apiVersion: external-secrets.io/v1alpha1
2kind: PushSecret
3metadata:
4 name: push-tls-cert
5 namespace: payments
6spec:
7 refreshInterval: 24h
8 secretStoreRef:
9 name: aws-secretsmanager
10 kind: SecretStore
11 selector:
12 secret:
13 name: payments-api-tls # Kubernetes Secret to push (e.g., cert-manager issued cert)
14 data:
15 - match:
16 secretKey: tls.crt # Key in the Kubernetes Secret
17 remoteRef:
18 remoteKey: payments/tls/certificate # Destination in AWS Secrets Manager
19 - match:
20 secretKey: tls.key
21 remoteRef:
22 remoteKey: payments/tls/private-keyFrequently Asked Questions
How does ESO differ from Vault Agent Injector?
The Vault Agent Injector adds a sidecar to every pod that fetches secrets directly from Vault and writes them to an in-memory volume. ESO syncs secrets to standard Kubernetes Secrets and doesn't require a sidecar per pod. ESO is simpler to operate (no sidecar lifecycle management, no Vault-specific pod annotations), supports multiple backends in the same cluster, and the secrets are visible to standard Kubernetes tooling. The tradeoff: ESO stores values in Kubernetes Secrets (etcd), so Kubernetes RBAC is your access control layer; Vault Agent provides finer-grained access using Vault policies directly.
How do I handle multi-region secret replication?
Deploy an ESO SecretStore or ClusterSecretStore per region, pointing at the Secrets Manager endpoint for that region. ExternalSecrets in each cluster reference the local region's store. AWS Secrets Manager supports cross-region replication — enable it on the source secret and use the regional endpoint in each cluster's SecretStore.
What happens if AWS Secrets Manager is unavailable?
ESO logs the error and does not update the Kubernetes Secret. The existing Secret value (from the last successful sync) remains in place. Pods continue reading the existing Secret. If the Secret doesn't exist yet (first sync failed), pods that depend on it will fail to start. ESO emits a SecretSyncError event and metric — monitor externalsecrets_sync_call_errors_total in Prometheus.
