AWS Load Balancer Controller: ALB and NLB for EKS
The AWS Load Balancer Controller provisions and manages ALBs and NLBs from Kubernetes Ingress and Service resources. It replaces the in-tree Kubernetes cloud provider integration for load balancers on EKS and gives you full control over ALB configuration — listener rules, target groups, WAF, OIDC authentication, and IngressGroups that share a single ALB across multiple services.
Before the AWS Load Balancer Controller, EKS used the in-tree Kubernetes cloud provider to provision load balancers — which created Classic Load Balancers for Services and provided no support for ALBs. The AWS Load Balancer Controller (formerly ALB Ingress Controller) replaced this with a controller that provisions ALBs (Application Load Balancers) for Kubernetes Ingress resources and NLBs (Network Load Balancers) for Services, with full access to ALB and NLB features through Kubernetes annotations.
The controller is now the standard approach for load balancing on EKS. Understanding its annotation model, IngressGroup feature, and target type options is essential for anyone operating EKS in production.
Installation
IAM Policy and Service Account
The controller needs IAM permissions to create and manage EC2 and ELB resources:
1# Download the IAM policy document
2curl -o iam-policy.json \
3 https://raw.githubusercontent.com/kubernetes-sigs/aws-load-balancer-controller/main/docs/install/iam_policy.json
4
5# Create the IAM policy
6aws iam create-policy \
7 --policy-name AWSLoadBalancerControllerIAMPolicy \
8 --policy-document file://iam-policy.json
9
10# Create PodIdentityAssociation (recommended over IRSA for new clusters)
11aws eks create-pod-identity-association \
12 --cluster-name my-cluster \
13 --namespace kube-system \
14 --service-account aws-load-balancer-controller \
15 --role-arn arn:aws:iam::123456789:role/AWSLoadBalancerControllerRoleAttach the policy to the IAM role and ensure the role's trust policy allows pods.eks.amazonaws.com.
Helm Install
1helm repo add eks https://aws.github.io/eks-charts
2helm repo update
3
4helm install aws-load-balancer-controller eks/aws-load-balancer-controller \
5 --namespace kube-system \
6 --set clusterName=my-cluster \
7 --set serviceAccount.create=true \
8 --set serviceAccount.name=aws-load-balancer-controller \
9 --set region=us-east-1 \
10 --set vpcId=vpc-xxxxxVerify the controller is ready:
kubectl get deployment -n kube-system aws-load-balancer-controller
# NAME READY UP-TO-DATE AVAILABLE AGE
# aws-load-balancer-controller 2/2 2 2 5mALB via Ingress
Create an ALB by creating a Kubernetes Ingress with ingressClassName: alb:
1apiVersion: networking.k8s.io/v1
2kind: Ingress
3metadata:
4 name: my-app
5 namespace: production
6 annotations:
7 # ALB scheme: internet-facing for public; internal for VPC-only
8 alb.ingress.kubernetes.io/scheme: internet-facing
9 # Target type: ip routes directly to pod IPs; instance routes via NodePort
10 alb.ingress.kubernetes.io/target-type: ip
11 # HTTPS listener + HTTP-to-HTTPS redirect
12 alb.ingress.kubernetes.io/listen-ports: '[{"HTTP":80},{"HTTPS":443}]'
13 alb.ingress.kubernetes.io/ssl-redirect: "443"
14 # ACM certificate ARN
15 alb.ingress.kubernetes.io/certificate-arn: arn:aws:acm:us-east-1:123456789:certificate/xxxxx
16 # SSL policy
17 alb.ingress.kubernetes.io/ssl-policy: ELBSecurityPolicy-TLS-1-2-2017-01
18 # Health check
19 alb.ingress.kubernetes.io/healthcheck-path: /healthz
20 alb.ingress.kubernetes.io/healthcheck-interval-seconds: "15"
21 alb.ingress.kubernetes.io/success-codes: "200-299"
22spec:
23 ingressClassName: alb
24 rules:
25 - host: api.example.com
26 http:
27 paths:
28 - path: /
29 pathType: Prefix
30 backend:
31 service:
32 name: api
33 port:
34 number: 80Target Type: ip vs instance
| Feature | ip | instance |
|---|---|---|
| Routing | Direct to pod IPs | Via NodePort |
| CNI requirement | VPC CNI (pods need real VPC IPs) | Any CNI |
| HTTP/2 | Supported | Supported |
| WebSocket | Supported | Supported |
| Latency | Lower (one fewer hop) | Slightly higher |
| Connection draining | Pod-level | Node-level |
Use ip when on VPC CNI (default on EKS) — it gives lower latency and pod-level health checks, so traffic drains from a pod being terminated rather than the entire node.
IngressGroup: Sharing One ALB
By default, each Ingress creates a separate ALB. ALBs cost ~$16/month plus data processing fees — a cluster with 50 services means 50 ALBs. IngressGroup consolidates multiple Ingresses onto a single ALB, with each Ingress adding listener rules:
1# Ingress for the API service
2apiVersion: networking.k8s.io/v1
3kind: Ingress
4metadata:
5 name: api
6 namespace: production
7 annotations:
8 alb.ingress.kubernetes.io/scheme: internet-facing
9 alb.ingress.kubernetes.io/target-type: ip
10 alb.ingress.kubernetes.io/certificate-arn: arn:aws:acm:...:certificate/xxxxx
11 alb.ingress.kubernetes.io/group.name: platform-alb # IngressGroup name
12 alb.ingress.kubernetes.io/group.order: "10" # Rule priority within the group
13spec:
14 ingressClassName: alb
15 rules:
16 - host: api.example.com
17 http:
18 paths:
19 - path: /
20 pathType: Prefix
21 backend:
22 service:
23 name: api
24 port:
25 number: 80
26---
27# Ingress for the dashboard — shares the same ALB
28apiVersion: networking.k8s.io/v1
29kind: Ingress
30metadata:
31 name: dashboard
32 namespace: production
33 annotations:
34 alb.ingress.kubernetes.io/scheme: internet-facing
35 alb.ingress.kubernetes.io/target-type: ip
36 alb.ingress.kubernetes.io/certificate-arn: arn:aws:acm:...:certificate/xxxxx
37 alb.ingress.kubernetes.io/group.name: platform-alb # Same group → same ALB
38 alb.ingress.kubernetes.io/group.order: "20"
39spec:
40 ingressClassName: alb
41 rules:
42 - host: dashboard.example.com
43 http:
44 paths:
45 - path: /
46 pathType: Prefix
47 backend:
48 service:
49 name: dashboard
50 port:
51 number: 80Both Ingresses share one ALB with separate listener rules. The ALB is named after the IngressGroup and persists even if individual Ingresses are deleted.
Multi-namespace IngressGroups: Ingresses across different namespaces can share an ALB by using the same group.name. The controller merges their rules. Ensure you control the group membership — a team adding group.name: platform-alb to their Ingress would join your shared ALB. Use RBAC or Kyverno to restrict which teams can set specific group names.
NLB via Service
Create an NLB by annotating a LoadBalancer Service:
1apiVersion: v1
2kind: Service
3metadata:
4 name: grpc-api
5 namespace: production
6 annotations:
7 service.beta.kubernetes.io/aws-load-balancer-type: external
8 service.beta.kubernetes.io/aws-load-balancer-nlb-target-type: ip
9 service.beta.kubernetes.io/aws-load-balancer-scheme: internet-facing
10 # TLS termination at NLB (pass-through to pods is also possible)
11 service.beta.kubernetes.io/aws-load-balancer-ssl-cert: arn:aws:acm:us-east-1:...:certificate/xxxxx
12 service.beta.kubernetes.io/aws-load-balancer-ssl-ports: "443"
13 # Cross-zone load balancing
14 service.beta.kubernetes.io/aws-load-balancer-cross-zone-load-balancing-enabled: "true"
15 # Preserve client IP (disable if using `ip` target type — pods see real client IPs already)
16 service.beta.kubernetes.io/aws-load-balancer-target-group-attributes: preserve_client_ip.enabled=false
17spec:
18 type: LoadBalancer
19 selector:
20 app: grpc-api
21 ports:
22 - name: grpc
23 port: 443
24 targetPort: 9090
25 protocol: TCPNLBs are preferable over ALBs for:
- gRPC or HTTP/2 workloads (ALBs support HTTP/2 but NLBs provide more transparent proxying)
- Very high throughput (NLBs handle millions of requests per second)
- Non-HTTP protocols (TCP/UDP)
- Ultra-low latency (NLBs have lower overhead than ALBs)
TargetGroupBinding
TargetGroupBinding connects a Kubernetes Service to an existing ALB/NLB target group. This is useful when the load balancer is created outside of Kubernetes (e.g., Terraform-managed ALB) and you want Kubernetes to manage target group registration:
1apiVersion: elbv2.k8s.aws/v1beta1
2kind: TargetGroupBinding
3metadata:
4 name: payments-tgb
5 namespace: production
6spec:
7 serviceRef:
8 name: payments-api
9 port: 80
10 targetGroupARN: arn:aws:elasticloadbalancing:us-east-1:123456789:targetgroup/payments/xxxxx
11 targetType: ip
12 networking:
13 ingress:
14 - from:
15 - securityGroup:
16 groupID: sg-alb-security-group
17 ports:
18 - port: 80
19 protocol: TCPThe controller registers and deregisters pod IPs with the target group as pods scale up and down. The target group health check is managed by ALB, but connection draining (deregistration delay) ensures in-flight requests complete before a pod is removed.
WAF and Shield Integration
Attach a WAF Web ACL to an ALB:
annotations:
alb.ingress.kubernetes.io/wafv2-acl-arn: arn:aws:wafv2:us-east-1:123456789:regional/webacl/my-waf/xxxxx
# Shield Advanced (requires subscription)
alb.ingress.kubernetes.io/shield-advanced-protection: "true"WAFv2 rules can block common attack patterns (OWASP Top 10, SQL injection, rate limiting) at the ALB layer, before traffic reaches your pods.
OIDC Authentication via Cognito or IAM Identity Center
ALB supports offloading OIDC authentication to the load balancer layer:
1annotations:
2 # Authenticate users before forwarding to the backend
3 alb.ingress.kubernetes.io/auth-type: oidc
4 alb.ingress.kubernetes.io/auth-idp-oidc: |
5 {
6 "issuer": "https://cognito-idp.us-east-1.amazonaws.com/us-east-1_xxxxx",
7 "authorizationEndpoint": "https://my-domain.auth.us-east-1.amazoncognito.com/oauth2/authorize",
8 "tokenEndpoint": "https://my-domain.auth.us-east-1.amazoncognito.com/oauth2/token",
9 "userInfoEndpoint": "https://my-domain.auth.us-east-1.amazoncognito.com/oauth2/userInfo",
10 "secretName": "oidc-client-secret"
11 }
12 alb.ingress.kubernetes.io/auth-on-unauthenticated-request: authenticate
13 alb.ingress.kubernetes.io/auth-scope: "openid profile email"The ALB redirects unauthenticated requests to the Cognito login page. After authentication, the ALB forwards requests to the backend with X-Amzn-Oidc-Identity and X-Amzn-Oidc-Accesstoken headers. This pattern works for internal dashboards and developer portals without embedding auth logic in the application.
Frequently Asked Questions
What's the difference between alb.ingress.kubernetes.io/scheme: internet-facing and internal?
internet-facing creates an ALB with a public DNS name and public IP addresses — accessible from the internet. internal creates an ALB with a private DNS name and VPC-internal IP addresses — only accessible from within the VPC or connected networks (VPN, Direct Connect). Use internal for ALBs that only receive traffic from within your AWS environment (e.g., service-to-service via ALB, admin dashboards accessible only over VPN).
How do I handle multiple certificates for different domains on the same ALB?
The controller supports alb.ingress.kubernetes.io/certificate-arn as a comma-separated list:
alb.ingress.kubernetes.io/certificate-arn: >
arn:aws:acm:us-east-1:...:certificate/cert1,
arn:aws:acm:us-east-1:...:certificate/cert2ALB serves the appropriate certificate based on SNI. For IngressGroups where different Ingresses cover different domains, each Ingress specifies its own certificate-arn and the controller combines them on the shared ALB.
The ALB health check is failing but my pods are healthy — what's wrong?
Common causes:
- Wrong health check path: Default health check is
/returning 200. Change withalb.ingress.kubernetes.io/healthcheck-path. - Security group blocking health checks: The ALB health check comes from the ALB's security group. Ensure the pod/node security group allows inbound traffic from the ALB security group on the service port.
- Target type mismatch: If
target-type: ipis set but pods don't have VPC IPs (not using VPC CNI), health checks will fail. Useinstanceif you're not on VPC CNI. - HTTP vs HTTPS: If the backend expects HTTPS but ALB sends HTTP health checks, use
alb.ingress.kubernetes.io/backend-protocol: HTTPSandalb.ingress.kubernetes.io/healthcheck-protocol: HTTPS.
Can I use the AWS Load Balancer Controller with Istio?
Yes, but the typical pattern is to put the ALB in front of the Istio ingress gateway (not directly in front of application pods). The ALB terminates external TLS, and Istio handles internal mTLS. Set alb.ingress.kubernetes.io/target-type: ip and point the Ingress backend to the istio-ingressgateway service. Alternatively, use NLB with TLS pass-through so Istio terminates TLS end-to-end.
For EKS networking that the AWS LBC builds on (VPC CNI, IP allocation), see EKS Networking Deep Dive. For TLS certificate automation that generates the ACM or cert-manager certificates referenced in ALB annotations, see cert-manager in Production.
